Medical Waste Incinerator
This medical waste incinerator employs advanced pyrolysis combustion technology to effectively manage various types of medical waste, including but not limited to disposable syringes and surgical supplies, ensuring thorough destruction and minimizing environmental impact. Moreover, the flue gas produced during incineration is treated through a multi-stage purification system to meet national emission standards, safeguarding the surrounding environment and public health. Our product is suitable not only for hospitals but also for clinics, laboratories, and other facilities, contributing to the creation of a cleaner and safer planet.
Product Details
Product Advantages:
1.High Efficiency and Environmental Protection: Advanced incineration fully decomposes harmful substances, and excellent exhaust gas purification leads to significant emission reduction.
2.Safety and Reliability: Multiple safety measures, precise temperature and pressure control, stable furnace body and high-quality refractory materials.
3.Thorough Disposal: Suitable for various medical wastes. Unique structures ensure complete combustion and harmless residues.
4.Automated and Intelligent Control: Intelligent and fully automated, optimizing parameters according to the situation, reducing errors and increasing efficiency.
5.Small Floor Area: Integrated and compact, with multiple modules integrated, occupying less space, widely applicable and cost-saving.
6.Energy Saving and Consumption Reduction: Waste heat recovery and reuse, excellent combustion process and insulation, saving energy and reducing costs.
Applications:
Infectious medical waste
Pathological medical waste
Injurious medical waste
Pharmaceutical Medical Waste
Chemical Medical Waste
Name | YHI-50 | YHI-100 | YHI-200 |
Dimensions | 1800*1150*2850mm（L*W*H） | 2000*1350*3550mm（L*W*H） | 2300*1500*3650mm（L*W*H） |
Garbage entrance size | 0*600mm（L*W） | 700*800mm（L*W） | 750*900mm（L*W*H） |
Incineration capacity | 30~50kg/h | 100~120kg/h | 150~200kg/h |
Induced draft fan | 0.75KW | KW | 1.1 KW |
Burner | 2 sets |
Voltage | 220V |
Fuel | Diesel fuel |
Fuel consumption per hour | Burner-1 ~5 L/HBurner-2 4~5 L/H | Burner-1 ~5 L/HBurner-2 4~5 L/H | -1 ~5 L/HBurner-2 7~8 L/H |
Total power | 1.1KW |
| 1.8 KW |
Feeding method | manual |
Ignition method | automatic |
Incineration temperature | Main combustion chamber 600~800 degrees, secondary combustion chamber 900~1100 degrees |
Floor space | 3*1.5 m | 3*2 m | 3.5*2 m |
Material | Shell: Welded steel plate. Firewall: monolithic prefabrication of refractory bricks and refractory concrete |
Chimney | m | Φ303*6000 mm | Φ303*6000 mm |
Weight | 2100kg | 3500kg | 4600kg |
-
